Automatic Roman-Pillar Slot Cutting Machine with 50Hz Frequency 1200*3500 Trolley Size and 20 Feet Container Transport Package

Name: Automatic RomanPillar Slot Cutting Machine with 50Hz Frequency 12003500 Trolley Size and 20 Feet Container Transport Package
Brand: Xianda Machinery
Price: 1 USD

China Automatic Roman-Pillar Slot Cutting Machine with 50Hz Frequency 1200*3500 Trolley Size and 20 Feet Container Transport Package wholesale

Brand Name : Xianda Machinery

Model Number : DLC-1400

Certification : API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF

Place of Origin : Jinjiang, Fujian, China

MOQ : 1

Price : To Be Negotiable

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability : 1000 Sets/Year

Delivery Time : 15 Days

Packaging Details : Wire rope lashing,Suitable for sea/air/land/rail transportation.

Safety Protection : High

Blade Qty : One

Frequency : 50Hz

Max Cutting Diameter : 1400mm

Trolley Size : 1200*3500

Power : 7.5kW

Transport Package : Load in a 20 Feet Container

Warranty : 1 year for parts

Contact Now

DLC-1400 Automatic Roman-Pillar Slot Cutting Machine

Product Snapshot

Turn fluted-column production into a one-operator job. The DLC-1400 is a micro-processor-controlled slotter engineered for Roman, Corinthian and Tuscan pillars from Φ450 mm up to Φ1 400 mm. Three-piece clamping, automatic index and a 7.5 kW direct-drive spindle deliver clean, chatter-free flutes at rates 3× faster than manual methods.

 Technical Specifications

  Parameter Unit DLC-1400
 Processing diameter (Three pieces) mm Ф450~Ф1400
 Trolley size mm 1200 x 3500
 Main motor kw 7.5
 Gross power kw 12.5
 Outline dimension mm 6500 x 2800 × 2800
 Gross weight kg ≈4000
 Water consumption m³/h ≈2


Why DLC-1400?Micro-Computer Accuracy
Three-Piece Assembly Ready
Accepts pre-glued three-segment columns up to 1.4 m Ø
Self-centering roller bed prevents segment shift during slotting
Grooves align perfectly across joints—no visible mismatch
Heavy-Duty Build, Low Vibration
4 t total weight + 6500 mm steel frame absorbs cutting forces
7.5 kW main motor maintains constant RPM under full load
2 m³/h water curtain cools tool and eliminates dust
Operator-Friendly Workflow
Place column on powered rollers
Enter groove count / depth on touch panel
Press START—head indexes automatically
Unload finished column—ready for polishing
Ideal ApplicationsRoman / Greek fluted columns
Hotel lobby pillars
Exterior façade balustrades
Garden column sets
Monumental architectural features
Quick SpecsProcessing diameter: 450 – 1400 mm
Table length: 3 500 mm (accepts columns ≤ 3.2 m)
Main motor: 7.5 kW
Total power: 12.5 kW
Water consumption: ~2 m³/h (recycled)
Machine weight: ≈ 4 000 kg
Foot-print: 6.5 × 2.8 × 2.8 m
Package & WarrantyExport crate: steel-frame + plywood
Delivery: 20 days (stock) / 30 days (custom colour)
Warranty: 12 months for parts
Installation: video-guide + remote support; on-site service optional
Get Quote in 12 h
